Abosn Floorball rink board  is made of extruded POLYPROPYLENE panels.

The rink set consists of three segment types: 2 m long segments, 1 m long segments and rounded corner segments.On request a segment of any lenght can be made.

Certified Barrier system for floorball, inner range 40 x 20 m, r=2,09m,

height 0,5m, high resistant polypropylene, special technology of welding (molecular weld).

The material for floorball rinks was tested in extremly high conditions,

 used on barrier system of outdoor street hockey rinks and universal outdoor field.


The individual segments consist of front impact shield (a rink panel), a floor panel, a top handrail,

two side-piece and one elastic cord. Used manufacturing technology ensures the product is sufficiently sturdy,

resilient, resistant, long-lasting and, if the need be, with easily repairable and replaceable structural parts of the product.

The rink surface is smooth on both side, being thus available for advertising both inside and outside.

 The standard rink colour is white,black and also blue.


The 40 by 20 meters size rink needs the following number of individual segments: 52 pcs of the 2 m, 4 pcs of the 1 m and 4 pcs of the rounded corners.


A 40 m long side of the rink need 18 pieces of the 2 m and 1 piece of the 1 m segment. A 20 m long side of the rink need 8 pieces of the 2 m and 1 piece of the 1 m segment.

A rounded corner is expected to be 1,5 m long on each rink side out of an imaginary corner point at an angle of 90°. Meanwhile Abosn can supply another type : rink splitter .

 Rink splitter is special kind of flooorball rink intended to split one big play-field into 2 or more.  And another special type : Wheelchair floorball rink .  Its height is 25 cm mostly .


Transport trolley


Transport trolley - 2pcs (zinc dipping). Easy manipulation with floorball rink segments.


Storage and shipment

The rink is stored


leisurely in horizontal position, with the maximum 10 pieces being stacked, one bottom edge over another. Stacking additional pieces over this standard 10-piece pile is not recommended as shape alterations in bottom pieces might occur.

on trolley (for ground 40 x 20 you need 2x trolleys)


They are easy to connect , take down , storage and transport . And can be used both indoor and outdoor , because the panels are UV resistant .

The floorball board can be used in beach , sport site , entertainment event , shopping mall , school , training club , etc .
