Abosn ( Dezhou) New Material Co., Ltd (www.abosnplastic.com), is the branch company of Xinxing Group, which has the biggest factory among Xinxing factories, it covers an area of 700,000.00 square feet, with an annual output of 50,000.00 tons of UHMWPE products.
UHMWPE sheets are 50% percent of the sales of the volume of our whole products, because of its extremely advantage of the property and wide application. Let us see one by one :
1. Chemical resistant UHMWPE dump truck liner durable chute liner (https://www.abosnplastics.com/uhmwpe-wear-resisting-liners/ )
2. UV-resistant UHMWPE marine fender pads dock bumpers for marine wall and harbor side protection pads ( https://www.abosnplastics.com/uhmwpe-marine-fender-pads/ )
3. high wear resistance UHMWPE HDPE plastic strip bar, chain guides
(https://www.abosnplastics.com/uhmwpe-blocks-and-strips/ )
4. uhmwpe dewatering suction box cover/UHMWPE dewatering uhmw scraper blade pulp (http://en.sdxxhg.com/product/404.html )
Our UHMW-PE pressing mould standard sizes:
1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:
2000*1000*(10-300)mm;
3000*1500*(10-300)mm;
4700*1200*(10-300)mm;
4500*2000*(10-300)mm;
5000*1300*(10-300)mm;
uhmwpe dewatering suction box
The properties of UHMW-PE sheets and machined parts :
Property | Unit | Value |
Density | g/cm3 | 0.93-0.96 |
Average molecular weight | g/mol | 3million- 10 million |
Tensile strength (23°C in the air) | MPa | 22 |
Breaking strength | MPa | 42 |
Tensile strain at break | % | 600 |
Charpy impact strength (notched) | MJ/mm2 | No break |
Ball indentation hardness | N/mm2 | 42 |
Shore D hardness | -- | 65-70 |
Abrasion | % | 70-80, steel = 100 |
Static Friction Coefficient | -- | ≤0.16 |
Kinetic Friction Coefficient | -- | ≤0.10 |
Water Absorption | -- | NIL |
Elongation at the break at 23 degrees | % | ≥300 |
Temperature resistance | °C | -269 to +85 |
Melt Temperature | °C | 130-140 |
Application of UHMWPE UHMWPE sheet :HM
Textile Industry |
Paper Industry |
Farm Implement |
Chemical Industry |
Material Handling |
Food Processing Industry |
Mining & Metals Processing Industries |
If your project needs this kind of property sheet, no hesitate to contact us.
